1045kWh
PV + Diesel Generator + Grid
BESS Container
Lower Operating Noise
Lower Operating Noise
Flexible Expansion
Lower Operating Noise
Plug-and-play
Lower Energy Consumption
PRODUCT FEATURES
PRODUCT PARAMETERS

Battery/Model

HybridCube-1045

Cell Type

LFP-314 Ah, Cycle Life≥ 8000 cycles

Voltage Range

728-936 V

Max. Charge/Discharge current

628 A

Rated Capacity

1045 kWh

Communication

ISO SPI

Max. Depth of Discharge

100%（25±2℃）

Photovoltaic Input


Recommended Max. Power

400(100*4) kW

Photovoltaic Voltage Range

150-900 V

Max. Input Current

700 A

Max. Input Series

2P CS

AC Side Output


Rated Power

500 (125*4) kW

Output Voltage

380-400 V

Output Frequency

50/60 Hz

Power Factor

＞0.99

AC Side Input


Input Voltage

380(-20%～+15%) V

Max. Input Current

700 A

Input Frequency

50/60±2.5 Hz

General


Temperature Range

-15°C-50°C

Dimensions（W*D*H)

6100*2438*2600 mm

Communication method

CAN、RS485、WIFI

Protection level

IP55

Certification standards

UN38.3、CE-EMC

Cooling

Liquid Cooling
Smart Solution for Energy Storage
